JVM Library - Gradle

Arg2p is available as a 2P-Kt library.

To import the Arg2p module (version 0.20.0) into your Kotlin-based Gradle project, declare the dependency in your build.gradle(.kts) file:

repositories {
   mavenCentral()
}

dependencies {
   implementation("it.unibo.tuprolog.argumentation:arg2p-jvm:0.20.0")
}

Usage Example

import it.unibo.tuprolog.argumentation.Arg2p

fun main() {
    val (graph) =
        Arg2p.of(
            """
            f1 :=> d.
            f2 :=> -d.
            """.trimIndent(),
        ).graphs()

    graph.labellings.forEach {
        println("${it.label} : ${it.argument.conclusion}")
    }
}

For a complete example, check out the GitHub demo.

Available modules

arg2p-jvm is the aggregate module: it brings in the API of Arg2P (Arg2p), with the core engine, the causality and the parallel solver, and is what most projects need. The individual modules can also be depended upon directly, all under the group it.unibo.tuprolog.argumentation:

Artifacts without a suffix are the Kotlin Multiplatform ones; use -jvm or -js to depend on a single platform explicitly.

NPM Library

The Arg2P software is available on NPM as a JavaScript library as well. It can be found under the @tuprolog organization. To use the library, add the dependency to your package.json:

{
  "dependencies": {
    "@tuprolog/arg2p": "0.20.0"
  }
}

Usage Example

import { Arg2p } from '@tuprolog/arg2p'

const [graph] = Arg2p.of(`
    f1 :=> d.
    f2 :=> -d.`).graphs()

graph.labellings.forEach(it => console.log(`${it.label} : ${it.argument.descriptor}`))

For a complete example, see the repository.

Python

The package arg2p runs the same API from Python: see Python.

Web Playground

The playground runs Arg2P in the browser, with nothing to install: write a theory, solve a query, and browse its argument graph and the stages of its computation; draw an abstract framework (the drawing is its theory), and set the profile and the flags. It keeps your theories in tabs, shares them as links, and works offline once installed as an app. Its components are on npm as @tuprolog/arg2p-ui, to embed the solver in other pages.

VS Code

The extension of VS Code edits theories as .arg2p files: their syntax errors show as they are typed, and Arg2P: Open the Solver opens the solver of the playground beside a theory, on the JVM. It bundles the language server of Arg2P and the Java runtime it runs on.

Federation and parallel solving

The switch Parallel of the solver solves the query on the parallel solver: any theory, flags and query (query mode too), on the workers of the language server, and on those of the devices linked to it. With none linked, it solves on the workers of this device alone, concurrently. The solver keeps the switch of each theory with its query and flags; the graph of a solution is that of the last stage of its computation, the stages before it are not kept.

The language servers of the same local network see each other: the view Arg2P Federation (in the explorer, or Arg2P: Show the Federation) shows the name of this device and its 4-digit code, and the devices nearby, each linked to once its code is typed (shown on that device); linked once, two devices link again by themselves while they run. It lists the devices linked with their workers, and New code refuses the code shown from then on.

A phone joins too: the view shows the QR code of a page the language server serves on the local network (http://<address>:<port>/). Scanned with a phone on the same network, the page asks for the code of the device, and the phone lends the workers of its Web Workers while the page stays open. The page loads @tuprolog/arg2p of the same version as the extension from jsDelivr.

The language server speaks of its federation with the requests arg2p/federation (its state), arg2p/federation/pair ({ site, code }), arg2p/federation/newCode, arg2p/federation/rename ({ name }) and arg2p/federation/enable ({ enabled }), each answered with the state, and the notification arg2p/federationChanged; the editor enables it with the options of initialize ({ federation: { enabled, name } }), and a query of the request arg2p/engine is solved on it with parallel: true.

AI assistants (MCP)

The language server of Arg2P is also an MCP server: AI assistants solve theories with it rather than guessing what they conclude. Its tools:

A theory that does not parse, or that its profile refuses, is an error of the tool saying why; a query is stopped after timeoutSeconds (60 by default).

explore is an MCP App: in the clients that show them (Claude, ChatGPT, VS Code), the solver of the playground appears in the conversation, runs the query, and lets the user browse its solutions, their argument graphs and stages, the drawing of an abstract framework and the flags, and solve again. Everywhere, its result links the web playground with the same theory, query and flags.

The plugin and its skills

The plugin arg2p bundles the MCP server with skills, the know-how of Arg2P for an assistant: arg2p-formalize (turning a problem into a theory, its profile and its flags), arg2p-solve (solving it, checking and reporting the result) and arg2p-explore (showing the user the solver). Its MCP server runs from the Python package with uv (uvx arg2p mcp).

The MCP server alone

The extension of VS Code registers it for the assistants of VS Code (Copilot agent mode): nothing to configure. Elsewhere, with uv (the Python package bundles its Java runtime), in Claude Code:

claude mcp add arg2p -- uvx arg2p mcp

In clients configured by JSON (Claude Desktop, Cursor, …):

{
  "mcpServers": {
    "arg2p": { "command": "uvx", "args": ["arg2p", "mcp"] }
  }
}

It is listed in the MCP Registry as io.github.tuProlog/arg2p. With Java 21 or later instead, download arg2p-lsp-0.20.0-redist.jar from the latest release and run java -jar arg2p-lsp-0.20.0-redist.jar --mcp.

The server speaks MCP over its standard input and output (protocol versions 2025-06-18, 2025-03-26 and 2024-11-05). Without --mcp, the same jar is the language server of Arg2P (the Language Server Protocol, over the same streams), for editors other than VS Code.
